Casmatic CMW208

High speed wrapper machine

Casmatic CMW 208 is a high speed tissue rolls wrapper for single layer pack configurations in one or two lanes at a maximum speed of 220 packs per minute. Casmatic CMW 208 guarantees efficient and reliable performances and high quality finished products.It is equipped with the traditional reciprocating wrapping cycle, with elevator and overhead flight unit hence it allows a positive product handling and final pack quality, regardless of the rolls softness or wrapping material (paper and/or poly) thickness.

High performance

Versatility

Sustainability

Main characteristics

Maximum mechanical speed 230 cycles/minute
Maximum production speed Up to 220 packs/minute
PLC platform Italy
Roll dimensions

Toilet roll dimensions:
Dia. 90 ÷ 135 mm; 135 ÷ 150 mm (speed limitations)
Length 90 ÷ 115 mm

Kitchen towel roll dimensions:
Dia. 100 ÷ 160 mm (one lane), 100 ÷ 140 (two lanes)
Length 190 ÷ 280 mm

Pack dimensions

Width 90 ÷ 280 mm
Length 90 ÷ 345 mm
Height 90 ÷ 152 mm

Wrapping material PE 18 ÷ 50 micron (for thickness <25 micron, contact our Technical Dept.)

*Please note that these are standard characteristics of the line. To receive additional information, contact us, clicking on "Request a free consultation"
